Sealey - MINIMIG160i - MIG/TIG & MMA (ARC/STICK) Inverter Welder 160A 230V

IGBT Inverter fan-cooled DC power supply for MIG/TIG and MMA/ARC welding applications up to 160A. Multi-functional welder bringing together MIG/TIG and MMA application all into one compact unit ideal for workshops, garages, bodyshops and mobile technicians. Ultra-compact and lightweight weighing just 6.9kg and supplied with handy carry strap making this unit highly portable allowing the welder to be taken to the job at hand. Featuring hot start, anti-stick, forced air cooling and thermal cut out protection. Unit can MIG weld using 1kg Ø0.8/0.9/1.0mm solid wire and Ø0.8/0.9mm flux cored MIG wire, MMA/ARC weld Ø1.6 up to Ø4.0mm electrode. Supplied with fixed non-live MIG torch, 1.4m earth cable/clamp, 1.6m electrode holder.

Model No MINIMIG160i
Brand: Sealey
Nett Weight: 6.9kg
Welding Current: 10-160A
Duty Cycle MIG: 60% @ 160A, 100% @ 124A
Duty Cycle MMA/ARC: 60% @ 160A, 100% @ 124A
Duty Cycle TIG: 60% @ 160A, 100% @ 124A
Wire Capacity: 1kg Ø0.8/0.9/1.0mm solid wire and Ø0.8/Ø0.9mm flux cored MIG wire
Electrode Capacity: 1.6-4mm
Absorbed Power: 4.4kW
Supply: 230V 16A*
Insulation Class: H
IP Rating: IP21S
Note * To achieve maximum power a 16A supply may be required.
