Home > Workshop Equipment > Air Compressors > Sealey - SAC2276B - 270L Belt Drive Air Compressor with Cast Cylinders 2 x 3hp
Sealey - SAC2276B - 270L Belt Drive Air Compressor with Cast Cylinders 2 x 3hp
SKU: SAC2276B
Part Number: SAC2276B
Barcode: 5051747560871
Country of Origin: ITA
Weight: 163.00 Kg
Our Price
£2,768.99 (inc VAT) £2,307.49 (ex VAT)
RRP £3,719.94 £3,099.95
Save
£950.95
£792.46
1 year Warranty included.
Description
High output unit suitable for the professional workshop. Fitted with two genuine 3hp motors and two identical pumps. Twin capacitors and a centrifugal switch aid trouble-free starting on a 230V 32A supply. This unit is supplied with a control box featuring a stepped start-up to prevent high Amp spikes. Pumps feature heavy-duty full cast cylinders, capped by alloy heads for improved heat dissipation and long-life. Heavy-duty drive guards protect belt and flywheel that is designed to force air over the pump to aid cooling.
Features
Model No SAC2276B
Air Displacement cfm(L/min): 30(850)
Brand: Sealey
Maximum Free Air Delivery cfm(L/min): 21.8(618)
Maximum Pressure: 145psi(10bar)
Minimum Rated Supply: 32A
Motor Output: 3hp (x2)
Nett Weight: 150kg
Oil Capacity: 2 x 0.72L
Outlet: 3/4"BSP Female Tap
Phase: 1ph
Receiver Capacity: 270L
Size (W x D x H): 1550 x 540 x 960mm
Speed: 1280rpm
Supply: 230V/32A
Air Displacement cfm(L/min): 30(850)
Brand: Sealey
Maximum Free Air Delivery cfm(L/min): 21.8(618)
Maximum Pressure: 145psi(10bar)
Minimum Rated Supply: 32A
Motor Output: 3hp (x2)
Nett Weight: 150kg
Oil Capacity: 2 x 0.72L
Outlet: 3/4"BSP Female Tap
Phase: 1ph
Receiver Capacity: 270L
Size (W x D x H): 1550 x 540 x 960mm
Speed: 1280rpm
Supply: 230V/32A
Specification
Workshopping Says
Warranty Period = 1 year years
Commodity code = 8414802290
Country of Origin = ITA
