Home > Workshop Equipment > Recovery & Towing > Sealey - ATV1135 - ATV/Quad Recovery Winch 1135kg (2500lb) Line Pull 12V
Sealey - ATV1135 - ATV/Quad Recovery Winch 1135kg (2500lb) Line Pull 12V
SKU: ATV1135
Part Number: ATV1135
Barcode: 5054511341560
Country of Origin: CHN
Weight: 12.10 Kg
Our Price
£222.84 (inc VAT) £185.70 (ex VAT)
RRP £299.94 £249.95
Save
£77.10
£64.25
1 year Warranty included.
Description
Suitable for ATV and quad bike mounting, these high-speed winches offer a combination of performance with durability. Designed and built with the toughest jobs in mind. High power 1.8kW (2.34hp) 12V DC permanent magnet type motor gives first class pulling power. Heavy-duty all-weather housing. 3-Stage planetary gears. Patented unique automatic spring brake, reliable in full load operation. Sliding ring gear clutch. High quality wire rope feeds through 4-way roller fairlead. IP67 rated motor and gearbox.
Features
Specification
Model No ATV1135
Brand: Sealey
Cable Minimum Brake Force: 22kN
Consumable Parts: ATV1135.WR - Wire Rope (Ø4.8mm x 15.2m) for ATV1135, ATV1135.DR - Dyneema Rope (Ø4.9mm x 15.2m) for ATV1135
Current Draw: No-Load - 26A, Maximum Load - 150A
Gear Ratio: 180:1
Line Pull*: 1135kg(2500lb)
Line Speed*: No-Load - 4.8m/min, Maximum Load - 1.6m/min
Motor Power: 1.8kW(2.34hp)
Nett Weight: 11.8kg
Note: *Performance quoted at first layer of cable on drum
Rated Capacity: Layer 1: 1135kg, Layer 5: 591kg
Supply: 12V
Wire Rope Diameter: 4.8mm
Wire Rope Length: 14m
Brand: Sealey
Cable Minimum Brake Force: 22kN
Consumable Parts: ATV1135.WR - Wire Rope (Ø4.8mm x 15.2m) for ATV1135, ATV1135.DR - Dyneema Rope (Ø4.9mm x 15.2m) for ATV1135
Current Draw: No-Load - 26A, Maximum Load - 150A
Gear Ratio: 180:1
Line Pull*: 1135kg(2500lb)
Line Speed*: No-Load - 4.8m/min, Maximum Load - 1.6m/min
Motor Power: 1.8kW(2.34hp)
Nett Weight: 11.8kg
Note: *Performance quoted at first layer of cable on drum
Rated Capacity: Layer 1: 1135kg, Layer 5: 591kg
Supply: 12V
Wire Rope Diameter: 4.8mm
Wire Rope Length: 14m
Workshopping Says
Warranty Period = 1 year years
Commodity code = 8425310000
Country of Origin = CHN
