Home > Workshop Equipment > Recovery & Towing > Sealey - PH12545 - Geared Winch with Brake 450kg Line Pull 12V
Sealey - PH12545 - Geared Winch with Brake 450kg Line Pull 12V
SKU: PH12545
Part Number: PH12545
Barcode: 5054630632662
Country of Origin: CHN
Weight: 15.50 Kg
Our Price
£387.85 (inc VAT) £323.21 (ex VAT)
RRP £479.94 £399.95
Save
£92.09
£76.74
1 year Warranty included.
Description
Steel drum is reinforced to make the product strong and durable. Rated IP68 weatherproof this winch will withstand any weather conditions. 3-Stage planetary gear train increased pull generated. 2-Brake system with a mechanical cone brake and a permanent motor dynamic brake work together to keep the load stable and protect the user.
Features
Model No PH12545
Brand: Sealey
Current Draw: 12V Full Load - 75A
Gear Ratio: 140:1
Line Pull*: 454kg 1000lbs
Line Speed*: Full Load - 3.8m/min
Motor Power: 12V - 1200W
Nett Weight: 11kg
Rated Capacity: 454kg 1000lbs
Specification:
Min. Breaking Rope Force: 4500lbs (2040kg)
Max. Rope Diameter: Ø5.4mm
Max. No. of Rope Winding Layers: 4 (Always Keep Working on First Layer)
Wire Rope Diameter: Ø4.8mm
Wire Rope Length: 18.3m
Brand: Sealey
Current Draw: 12V Full Load - 75A
Gear Ratio: 140:1
Line Pull*: 454kg 1000lbs
Line Speed*: Full Load - 3.8m/min
Motor Power: 12V - 1200W
Nett Weight: 11kg
Rated Capacity: 454kg 1000lbs
Specification:
Min. Breaking Rope Force: 4500lbs (2040kg)
Max. Rope Diameter: Ø5.4mm
Max. No. of Rope Winding Layers: 4 (Always Keep Working on First Layer)
Wire Rope Diameter: Ø4.8mm
Wire Rope Length: 18.3m
Specification
Description
Steel drum is reinforced to make the product strong and durable. Rated IP68 weatherproof this winch will withstand any weather conditions. 3-Stage planetary gear train increased pull generated. 2-Brake system with a mechanical cone brake and a permanent motor dynamic brake work together to keep the load stable and protect the user.
Features
Model No PH12545
Brand: Sealey
Current Draw: 12V Full Load - 75A
Gear Ratio: 140:1
Line Pull*: 454kg 1000lbs
Line Speed*: Full Load - 3.8m/min
Motor Power: 12V - 1200W
Nett Weight: 11kg
Rated Capacity: 454kg 1000lbs
Specification:
Min. Breaking Rope Force: 4500lbs (2040kg)
Max. Rope Diameter: Ø5.4mm
Max. No. of Rope Winding Layers: 4 (Always Keep Working on First Layer)
Wire Rope Diameter: Ø4.8mm
Wire Rope Length: 18.3m
Brand: Sealey
Current Draw: 12V Full Load - 75A
Gear Ratio: 140:1
Line Pull*: 454kg 1000lbs
Line Speed*: Full Load - 3.8m/min
Motor Power: 12V - 1200W
Nett Weight: 11kg
Rated Capacity: 454kg 1000lbs
Specification:
Min. Breaking Rope Force: 4500lbs (2040kg)
Max. Rope Diameter: Ø5.4mm
Max. No. of Rope Winding Layers: 4 (Always Keep Working on First Layer)
Wire Rope Diameter: Ø4.8mm
Wire Rope Length: 18.3m
